Tamiya RC Citroen DS - MB-01 - Item #58734

Tamiya RC Citroen DS - MB-01 - Item #58734

1/10 Scale 2WD

This R/C assembly kit recreates the Citroën DS which made its debut in 1955 and caught people’s attention with its innovative structure and style.

Over 1,450,000 were sold up to 1975, and it became one of the better- known cars of the 20th century. This car was used as the official car for the President of France and achieved the overall championship in 1966 global rallies.

The version recreated in this assembly kit recreates the early-period model featuring two rounded headlights. The polycarbonate body sits on top of the MB-01 chassis configured in the long wheelbase and front motor / front wheel drive (FF) configuration.

The MB-01 Chassis

The compact, 2WD MB-01 chassis gives a choice of three types of wheelbases, and front or rear wheel drive system.

This model employs a midship motor, rear-wheel drive setup. Without removing battery pack, motor, and R/C equipment setups from the centre frame, simply change attachment directions of final gears and steering linkage to switch between front- and rear-wheel drive; low or high motor position can be chosen for rear-wheel drive cars.

The 4-wheel double wishbone suspension features symmetrical structure and friction dampers. Unitised sections such as motor mount, final gears and suspension facilitate ease of assembly and effective maintenance

MB-01 Chassis Features

• 1/10 scale R/C model assembly kit. Length: 419mm, width: 198mm, height: 137mm. Wheelbase: 239mm (Long wheelbase).
• Polycarbonate body.
• Just like the actual vehicle, the front tread is wider than the rear tread.
• Features 60mm front and rear tires.
• Includes ESC and 540-brushed type motor.
• Required to complete: 2-channel radio, steering servo, 7.2-7.4volt battery with compatible charger, and Tamiya PS polycarbonate paint.

*Requires: 2-channel radio, steering servo, 7.2volt battery and compatible charger and Tamiya PS Paint to complete

SPECIFICATIONS

• Adjustable Gear Ratio - Yes
• Bearings - Plastic bushing
• Body Material - Polycarbonate
• Body Stickers - Included
• Chassis Material - ABS Plastic
• Chassis Type - MB-01
• Construction Type - Assembly Kit
• Differential Type - Gear
• Drive Type - 2WD
• Electronic Speed Control (esc) - Includes HobbyWing THW 1060 Brushed Motor ESC (2-3S)
• Motor - 540-brushed type
• Required To Complete - 2-channel radio, steering servo, 7.2-7.4volt battery & battery charger, and Tamiya PS paint.
• Scale - 1/10
• Shock Damper - Friction type
• Suspension - Fully Independent Double Wishbone
• Terrain Use - On-Road
